Power Output=2Vrms
THD+N Ratio=0.009%
SNR=102dB
Crosstalk=-106dB
Dynamic Range=96dB
Description
Product Details
Super easy setup
WiiM Mini will pop up automatically in the WiiM Home app. Follow the in-app guide
and start streaming music in less than 2 minutes.
Stream Hi-Res audio up to 192 kHz/24 bit.
WiiM Mini supports up to 192kHz, 24-bit audio output. That's the same as an artist's recording in the studio. The integrated TI stereo DAC provides high-quality analog audio output with 106-dB SNR, dynamic range, and -92dB THD+N performance.
All your content in one app
We support many popular music streaming services in our WiiM Home app with more to come. Or connect to your NAS or local files to stream your favorite music.
Specifications
Audio Codec
MP3, AAC, ALAC, APE, FLAC, WAV, WMA, OGG
Wi - Fi
Dual band Wi-Fi supports 802.11 a/b/g/n/ac 2.4 GHz and 5 GHz network
Bluetooth
Bluetooth 5.2, SBC and AAC codec, BT receiver and transmitter (with SW update)
Line in
1Vrms
Line out
Line in to Line out：
BT in to Line out：
Power Output=2Vrms
THD+N Ratio=0.009%
SNR=102dB
Crosstalk=-106dB
Dynamic Range=96dB
THD+N Ratio=0.009%
SNR=102dB
Crosstalk=-106dB
Dynamic Range=96dB
SPDIF
Line in to SPDIF out：
Power Output=-3dBFS
THD+N Ratio=0.005%
SNR=102dB
Crosstalk=-103dB
Dynamic Range=97dB
THD+N Ratio=0.005%
SNR=102dB
Crosstalk=-103dB
Dynamic Range=97dB
BT in to SPDIF out：
Power Output=0dBFS
THD+N Ratio=0.005%
SNR=297dB
Crosstalk=-364dB
Dynamic Range=213dB
THD+N Ratio=0.005%
SNR=297dB
Crosstalk=-364dB
Dynamic Range=213dB
Power Supply
5V,1A
LED
Three color status LED - Red, Green and White.
Button
Capacitive touch - Play/Pause, Volume+, Volume-
Package Contents
User Guide *1
Power Adapter *1（Availability varies by region）
Power Cable *1
RCA Cables *2
Optical Cable *1
Power Adapter *1（Availability varies by region）
Power Cable *1
RCA Cables *2
Optical Cable *1
