Description
Ubiquiti UTP-G3-Touch-Wall UniFi Talk Phone G3 Touch Wall
Product Details
Next-generation wall-mountable smartphone for UniFi Talk, featuring a 7" touch display and seamless integration with UniFi applications.
Specifications
Dimensions: 254.4 x 202.5 x 70.1 mm (10 x 8 x 2.8”)
UniFi Application Suite
Talk: ✓
Talk Relay: ✓
Mounting: Wall
Integrated Camera: ✓
Touch Screen Technology: Multi-Touch
Bluetooth:✓
Available Colors: Black
Mechanical
Weight: 1.1 kg (2.5 lb)
Enclosure Material: Polycarbonate, aluminum alloy (base)
Hardware
Connectivity: (2) GbE RJ45 ports 802.11 a/b/g/n/ac WiFi Bluetooth® 4.2 (General use) Bluetooth® 5.2 (Ubiquiti G3 Wireless Handset only) NFC support
Power Method: USB type-C 5V DC, 3A PoE 44—57V DC, 15.4W
Max. Power Consumption: 11W
Processor: Octa-core ARM® Cortex®-A53
Memory: Storage: 32 GB RAM: 2 GB
Camera: 2592 x 1944, 5MP (Embedded Privacy shutter)
Display: Screen Surface Treatments
Anti-Glare Coating
Size: 178 mm (7") diagonal
Resolution: 1280 x 800 HD
Audio: Hands-Free Microphone
Dual omnidirectional MEMS microphone
Hands-Free Speaker
Dual 3W speaker
Handset Microphone
Omnidirectional electret condenser microphone
Handset Dynamic Receiver
Standard wideband-capable audio
Buttons: (1) Mute Button
LED: R/G/B/W
NFC Frequency: 13.56 MHz
NFC Read Range: < 10 mm
NFC Technology: ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T
Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
Ambient Operating Humidity: 10 to 90% noncondensing
NDAA Compliant: ✓
Certifications: FCC, IC, CE
Features
- Easily integrates with 3rd party PBX platforms using Talk Relay
- Optional G3 Wireless Handset for added flexibility
- High-performance speakerphone for clear audio
- Ergonomic handset with a mute button
- Bluetooth connectivity for added versatility
