Description
Product Details
A 24-port, Layer 3 switch capable of high-power PoE++ output.
Specifications
|
|
MECHNICAL |
|
Dimensions |
442 x 285 x 44 mm (17.4 x 11.2 x 1.7") |
|
Weight |
Without mounting brackets: 4.3 kg (9.5 lb) With mounting brackets: 4.4 kg (9.7 lb) |
|
Enclosure material |
SGCC steel |
|
|
HARDWARE |
|
Management interface |
Ethernet In-Band |
|
Networking interface |
(24) GbE RJ45 ports (2) 1G SFP ports |
|
PoE interface |
(16) PoE/PoE+ (Pins 1, 2+; 3, 6-) (8) 60W PoE++; PoE/PoE+ (Pins 1, 2+; 3, 6-) / PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) |
|
Total non-blocking throughput |
44 Gbps |
|
Switching capacity |
88 Gbps |
|
Forwarding rate |
65.472 Mpps |
|
Power method |
(1) Universal input, 100—240V AC, 50/60 Hz |
|
Power supply |
AC/DC, internal, 450W |
|
Supported voltage range |
100 - 240V AC |
|
Max. power consumption |
50W (Excluding PoE output) |
|
Total available PoE |
400W |
|
Max. PoE wattage per port by PSE |
PoE+: 32W |
|
Voltage range PoE mode |
PoE: 44—57V |
|
ESD/EMP protection |
Air: ± 16kV, contact: ± 12kV |
|
Button |
Factory reset |
|
LCM display |
(1) 1.3" touchscreen |
|
Shock and vibration |
ETSI300-019-1.4 Standard |
|
Ambient operating temperature |
-10 to 40° C (23 to 104° F) |
|
Ambient operating humidity |
10 to 90% Noncondensing |
|
Certifications |
CE, FCC, IC |
|
|
SWITCHING FEATURES |
|
Layer 2 features |
IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs |
|
Layer 3 features |
DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs |
|
|
LEDs |
|
System |
Status |
|
Ethernet |
PoE |
|
SFP+ |
Link/activity |
|
RPS |
Status |
|
|
APPLICATION REQUIRNMENTS |
|
UniFi networks |
Version 5.10.5 and later |
