TRENDnet TPE-BG5091 9-Port 2.5G GaN Power PoE++ Switch with 10G SFP+ Port (480W)
Expand your network’s bandwidth and reduce traffic bottlenecks with TRENDnet’s 9-Port 2.5G GaN Power PoE++ Switch with 10G SFP+ Port (480W), model TPE-BG5091. This 2.5G PoE++ switch is equipped with 2.5GBASE-T RJ-45 ports that provide multi-gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. The 10G SFP+ port provides a high- speed 10Gbps network uplinks or downlinks over long distances. This multi-gigabit PoE++ switch features a durable metal enclosure and can be rack mounted for setup flexibility.
TRENDnet’s reliable 2.5G PoE++ switch is a cost-effective solutions to increase your network’s throughput. A 480W total PoE power budget on this multi-gig PoE++GaN -powered network switch supplies up to 95W per PoE port. Easily network PoE devices, such as high-power wireless access points, IP cameras, digital signage, IPTV decoders, access controls, and more with this high-power 2.5 gigabit PoE++ switch.
This PoE++ switch uses GaN power technology. GaN technology allows power supply designs to be smaller and more efficient. Compared with traditional power supplies, a GaN power supply takes up to 40% less foot print, and the increased efficiency reduces heat generated by the internal power supply.
Specifications
| Standards |
- IEEE 802.1p
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3ab
- IEEE 802.3ae
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.3bt
- IEEE 802.3bz
|
| Device Interface |
- 8 x 2.5GBASE-T PoE++ ports
- 1 x 10G SFP+ ports
- LED indicators
|
| Data Transfer Rate |
- Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
- Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
- Gigabit: 2Gbps (full duplex)
- 2.5 Gigabit: 5Gbps (full duplex)
- Gigabit SFP: 2Gbps (full duplex)
- 10G SFP+: 20Gbps (full duplex)
|
| Performance |
- Data RAM Buffer: 1MB
- Switch Capacity: 60Gbps
- MAC Address Table: 4K entries
- Forwarding rate: 44.64Mpps (64-byte packet size)
- Jumbo Frame: 12KB
|
| Power |
- Input: 100 – 240V AC, 50/60Hz, internal power supply
- Max. consumption: 16.5W (no PD)
|
| PoE |
- PoE budget: 480W
- PoE++: Up to 95W per port
- Pins 1, 2, 7, 8 for power - and pins 3, 6, 4, 5 for power +
- Over current protection
- Short circuit protection
|
| Fan/Acoustics |
|
| MTBF |
|
| Operating Temperature |
- 0° – 40° C (32° – 104° F)
|
| Operating Humidity |
|
| Dimensions |
- 330 x 220 x 44mm (13 x 7.87 x 1.73 in.)
|
| Weight |
|
| Certifications |
|
| Warranty |
|
Features
- 8 x 2.5G PoE++ ports
- 1 x 10G SFP+ ports
- 480W PoE power budget
- High- efficiency GaN internal power supply
- Backwards compatible with 10/100/1000Mbps devices
- Compatible with existing Cat5e or better cabling
- Rack mountable for installation flexibility
- 60Gbps switching capacity
- IEEE 802.3bz (2.5G) compliant
- Supports IEEE 802.3af/at/bt
- NDAA / TAA compliant (U.S. and Canada only)
- Lifetime Warranty*
|
PACKAGE CONTENTS
|
- TPE-BG5091
- Rackmount kit
- Power cord (1.5m / 4.9 ft.)
|
