TRENDnet TPE-BG102G 10-Port Gigabit PoE++ Switch
TRENDnet TPE-BG102G 10-Port Gigabit PoE++ Switch
TRENDnet TPE-BG102G 10-Port Gigabit PoE++ Switch
Roll over image to zoom in Click on image to zoom
TRENDnet TPE-BG102G 10-Port Gigabit PoE++ SwitchTRENDnet TPE-BG102G 10-Port Gigabit PoE++ SwitchTRENDnet TPE-BG102G 10-Port Gigabit PoE++ Switch

TRENDnet TPE-BG102G 10-Port Gigabit PoE++ Switch

TRENDnetSKU: TPE-BG102g
Price:

Login to see pricing

MSRP:
$319.99
Stock:
Call for availability

Description

TRENDnet TPE-BG102G 10-Port Gigabit PoE++ Switch

NDAA/TAA Compliant

Product Details

TRENDnet’s Unmanaged Gigabit PoE++ Switches provide high bandwidth performance, ease of use, and reliability. These IEEE 802.3bt compliant switches feature a sturdy 1U 19” rack mountable metal housing with mounting brackets included. These high power PoE++ switches also offer SFP slots for long distance fiber network applications.

Installers and integrators can save on equipment costs and reduce installation time with TRENDnet’s unmanaged high power PoE++ switches by delivering up to 95W per port of PoE++ power and data over existing Ethernet cables. Easily network PoE devices such as high-power wireless access points, PTZ cameras, digital signage, IPTV decoders, access controls, and more with these high power PoE++ switches.

Specifications

Standards
  • IEEE 802.1p
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3bt
Device Interface
  • 4 x Gigabit PoE++ ports
  • 4 x Gigabit PoE+ ports
  • 2 x Gigabit SFP Slots
  • LED indicators
Data Transfer Rate
  • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
  • Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
  • Gigabit: 2000Mbps (full duplex)
  • Fiber: 2000Mbps (full duplex)
Performance
  • Switch Fabric: 20Gbps
  • RAM Buffer: 512KB
  • MAC Address Table: 8K entries
  • Forwarding Rate: 14.88Mpps (64-byte packet size)
  • Jumbo Frames: 9KB
Power
  • Input: 100-240V AC, 50/60Hz, internal power supply
  • Max. Consumption: 280W
PoE
  • PoE budget: 240W
  • Port 1 – 4: up to 95W
  • Port 5 – 8: up to 30W
MTBF
  • 427,588 hours
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 330 x 230 x 44mm (13 x 9.0 x 1.7 in.)
Weight
  • 1.7kg (3.74 lbs.)
Certifications
  • CE
  • FCC
  • ETL
Warranty



Features

  • 4 x Gigabit PoE++ ports (up to 95W)
  • 4 x Gigabit PoE+ ports (up to 30W)
  • 2 x Gigabit SFP Slots
  • 240W PoE power budget
  • 20Gbps switching capacity
  • Internal power supply
  • Sturdy 1U 19” rack mountable metal housing
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*

PACKAGE CONTENTS
  • TPE-BG102g
  • Quick Installation Guide
  • Rackmount kit
  • Power Cord
