TRENDnetSKU: TEG-S750
Price:

Login to see pricing

MSRP:
$299.99
Stock:
Call for availability

Description

TRENDnet TEG-S750 5-Port 10G Switch

NDAA/TAA Compliant

Product Details

TRENDnet’s 5-Port 10G Switch, model TEG-S750, provides advanced high bandwidth performance, ease of use, and reliability. The TEG-S750 10G switch features five dedicated 10G ports for high-speed network connections with a 100Gbps switching capacity. With a sturdy compact metal housing and fanless design, the 10G switch is a reliable and cost-effective switch solution for high-speed 10 Gigabit network connections. This versatile unmanaged 10G switch also supports 2.5G-BASE-T connections for faster throughput over your existing Cat5e cabling (or better).

Specifications

Standards
  • IEEE 802.1x
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3an
  • IEEE 802.3az
  • IEEE 802.3bz
Device Interface
  • 5 x 10G ports (1Gbps/2.5Gbps/10Gbps)
  • LED indicators
Data Transfer Rate
  • Gigabit Ethernet: 2000Mbps (full duplex)
  • 2.5 Gigabit Ethernet: 5Gbps (full duplex)
  • 10 Gigabit Ethernet: 20Gbps (full duplex)
Performance
  • Switching fabric: 100Gbps
  • RAM buffer: 2MB
  • MAC address table: 16K entries
  • Jumbo frames: 12KB
  • Forwarding mode: store and forward
  • Forwarding rate: 74.4Mpps (64-byte packet size)
Power
  • Input: 100 – 240V AC, 50/60 Hz
  • Output: 12V, 3A
  • Max. consumption: 22.75W
MTBF
  • 521,600 hours
Fan / Acoustics
  • Fanless
Operating Temperature
  • 0° C – 40° C (-4° F – 122° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 180 x 145 x 33mm (7 x 5.7 x 1.3 in.)
Weight
  • 2.2kg (4.85 lbs.)
Certifications
  • CE
  • FCC
  • IC
  • LVD
  • UKCA
Warranty


Features

  • 5 x 10G RJ-45 ports
  • Supports IEEE 802.3bz 2.5G BASE-T over Cat5e cabling (or better)
  • Supports IEEE 802.3an 10G BASE-T over Cat6A cabling (or better)
  • 100Gbps switching capacity
  • Fanless design for silent operation
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*

PACKAGE CONTENTS
  • TEG-S750
  • Quick Installation Guide
  • Power Adapter (12V, 3A)
  • Wall mount kit
