Description

TRENDnet TEG-S7102 10-Port 10G Unmanaged Switch

NDAA/TAA Compliant

Product Details

Expand your network’s bandwidth and reduce traffic bottlenecks with TRENDnet’s Unmanaged 10G Switches. This 10G switch comes equipped with eight 10GBASE-T RJ-45 ports that provide speeds capable of up to 10Gbps over your existing Cat6A or better cabling. The 10G switch also offers two dedicated 10G SFP+ slots for high-speed network connections, providing a cost-effective solution in adding 10G link capability to an SMB network. The smart fan design lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable 10G switches are cost-effective solutions to increase your network’s throughput.

Specifications

Standards
  • IEEE 802.3ab
  • IEEE 802.3ae
  • IEEE 802.3an
  • IEEE 802.3az
  • IEEE 802.3bz
  • IEEE 802.1x
Device Interface
  • 8 x 10G ports (1Gbps/2.5Gbps/10Gbps)
  • 2 x 10G SFP+ ports (1Gbps/10Gbps)
  • LED indicators
Data Transfer Rate
  • Gigabit Ethernet: 2000Mbps (full duplex)
  • 2.5G Ethernet: 5Gbps (full duplex)
  • 10 Gigabit Ethernet: 20Gbps (full duplex)
  • 10G SFP+: 20Gbps (full duplex)
Performance
  • Switch fabric: 200Gbps
  • RAM buffer: 2MB
  • MAC address table: 32K entries
  • Jumbo frames: 12KB
  • Forwarding mode: Store and forward
  • Forwarding rate: 148.8Mpps (64-byte packet size)
Power
  • Input: 90 – 264V AC, 47/63 Hz. Internal power supply
  • Max. consumption: 40W
MTBF
  • 151,765 hours
Fan / Acoustics
  • Quantity: 1
  • Max. noise level: 47dBA
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 330 x 230 x 44mm (13 x 9 x 1.73 in.)
Weight
  • 2.54 kg (5.6 lbs.)
Certifications
  • CE
  • FCC
  • LVD
  • ETL
Warranty



Features

  • 8 x 10G RJ-45 ports
  • 2 x 10G SFP+ ports
  • Smart fan design eliminates noise
  • Rackmount design
  • 200Gbps switching capacity
  • IEEE 802.3ae (SFP+) and IEEE 802.3an (RJ-45) compliant
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*

PACKAGE CONTENTS
  • TEG-S7102
  • Quick Installation Guide
  • Power cord (1.5m / 4.9ft.)
  • Rackmount kit
