TRENDnet TEG-S708 8-Port 10G Unmanaged Switch
TRENDnet TEG-S708 8-Port 10G Unmanaged Switch
TRENDnet TEG-S708 8-Port 10G Unmanaged Switch
Roll over image to zoom in Click on image to zoom
TRENDnet TEG-S708 8-Port 10G Unmanaged SwitchTRENDnet TEG-S708 8-Port 10G Unmanaged SwitchTRENDnet TEG-S708 8-Port 10G Unmanaged Switch

TRENDnet TEG-S708 8-Port 10G Unmanaged Switch

TRENDnetSKU: TEG-S708
Price:

Login to see pricing

MSRP:
$434.99
Stock:
Call for availability

Description

TRENDnet TEG-S708 8-Port 10G Unmanaged Switch

NDAA/TAA Compliant

Product Details

TRENDnet’s 8-Port 10G Unmanaged Switch, model TEG-S708, is a multi-gig switch that provides advanced high-bandwidth performance, ease of use, and reliability. The TEG-S708 multi-gig switch offers eight dedicated 10G ports for high-speed network connections with a 160Gbps switching capacity and a sturdy, rack mountable metal housing. This 10G switch is a cost-effective switch solution for high-speed 10 Gigabit network connections.

Specifications

Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3z
  • IEEE 802.3ab
  • IEEE 802.3an
  • IEEE 802.3bz
Device Interface
  • 8 x 10GBASE-T ports (1Gbps/2.5Gbps/10G)
  • LED indicators
Data Transfer Rate
  • Gigabit: 2000Mbps (full duplex)
  • 2.5 Gigabit: 5Gbps (full duplex)
  • 10 Gigabit: 20Gbps (full duplex)
Throughput & Distance
  • Cat5e Cabling: 1Gbps @ 100m (328 ft.)
  • Cat6 Cabling: 10Gbps @ 50m (164 ft.)*
  • Cat6a Cabling: 10Gbps @ 100m (328 ft.)*
Performance
  • Switching Capacity: 160Gbps
  • RAM Buffer: 1.5MB
  • MAC Address Table: 16K entries
  • Forwarding Rate: 115.9Mpps (64-byte packet size)
  • Jumbo Frames: 12KB
Special Features
  • Rack Mountable
Power
  • Input: 100 – 240V AC, 50/60 Hz, 2.0A, internal power supply
  • Max. Consumption: 34.128W
Fan/Acoustics
  • Quantity: 1
  • Noise Level: 55dB(A) (max.)
MTBF
  • 674,176 hours
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions (L x W x H)
  • 264 x 184 x 43mm (10.39 x 7.24 x 1.69 in.)
Weight
  • 1.63g (3.6 lbs.)
Certifications
  • FCC
  • CE
  • ETL
Warranty



Features

  • 8 x 10G RJ-45 ports
  • Compatible with existing Cat6A or better cabling for 10Gbps
  • Backward compatible Ethernet speeds of 1000Mbps and 2.5Gbps with Cat5e or better cabling
  • Smart fan
  • 160Gbps switching capacity
  • IEEE 802.3bz (2.5G) and IEEE 802.3an (10G) compliant
  • Rack mountable
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*

PACKAGE CONTENTS
  • TEG-S708
  • Quick Installation Guide
  • Rack Mount Kit
  • Power Cord (1.5m / 4.9 ft.)
