Description
Product Details
2″L×.38″W×.39″H Center Lead Surface Mount Type
- Contact Size: 2″L×.38″W×.39″H
(50.8mm×9.6mm×10mm) - Standard Magnet Size: 2″L×.38″W×.39″H
(50.8mm×9.6mm×10mm) - Standard Gap: .75″(19mm)
- Colors: White, Brown
- 12″(305mm) 22 AWG Leads Standard
- Longer leads available.
Specifications
Part Number: TANE-55
Gap Inch (mm): .75″(19)
Loop: Closed
Reed Form: Normally Open
Max. Contact Rating (W): 10
Max. Initial Contact Resistance (mΩ): 100
Max. Switching Voltage (V): AC110/DC100
Max. Switching Current (A): 0.5
