Description
Product Details
Extreme protection for Home & Commercial High value properties
The High Security Field is created by balancing the external and internal magnetic fields.
Attempting to bring an external magnet to defeat the security switch triggers the alarm.
Specifications
Part Number: GP-23 HS
Gap Inch (mm): .39″~.94″ (10~24)
Loop: Closed
Reed Form: Normally Open
Max. Contact Rating (W): 3
Max. Initial Contact Resistance (mΩ): 100
Max. Switching Voltage (V): 30
Max. Switching Current (A): 0.2
Downloads
