Description
Yamaha AVENTAGE 9.2-Channel AV Receiver with 8K HDMI and MusicCast
Hear every sound, see every detail. The A6A has been carefully designed so every element of your entertainment is the best it can be. From slight whispers of sound to swift, on-screen movements, the A6A ensures you won’t miss a thing.
- 9.2-channel (with 11.2-channel processing) 150-Watt surround sound with Zone 2/3/4
- 4K120 and 8K60 HDMI and HDR10+ with HDCP 2.3 and eARC (7 in/3 out)
- Dolby Atmos® with Dolby Atmos Height Virtualization and DTS:X® with CINEMA DSP HD3
- ESS SABRE ES9026PRO Ultra DAC for the ultimate high-performance conversion
- YPAO™- R.S.C. with 3D, multipoint measurement, precision EQ and low frequency mode
- Surround:AI™ technology automatically optimizes the sound and effects in real-time
- ALLM, VRR and Dolby Vision™, Hybrid-Log Gamma and BT.2020
- AURO-3D
- Wi-Fi, Bluetooth®, MusicCast multi-room audio, AirPlay 2 and Spotify Connect
- Pandora, Spotify, SiriusXM, TIDAL, Deezer, Qobuz, Amazon Music HD
- Works with Sonos: seamlessly unites with a Sonos system using a Sonos Port (sold separately)
- 3rd-party control driver-capable, easy IP set-up and remote IP control
- Phono input
|
|
||||
|---|---|---|---|---|
| Amplifier Section | Channels | 9.2 | ||
| Rated Output Power (20Hz-20kHz, 2ch driven) | 150 W (8 ohms, 0.06% THD) | |||
| High Slew Rate Amplifier | Yes | |||
| Surround Sound Processing | Surround:AI | Yes | ||
| Cinema DSP | Yes (HD3) | |||
| DSP Programs | 24 | |||
| Dialog Level Adjustment | Yes | |||
| Virtual Presence Speaker | Yes | |||
| Virtual Surround Back Speaker | Yes | |||
| Dialogue Lift | Yes | |||
| SILENT Cinema / Virtual Cinema DSP | Yes | |||
| Dolby Atmos | Yes | |||
| Dolby Atmos Height Virtualization | Yes | |||
| Dolby TrueHD | Yes | |||
| Dolby Digital Plus | Yes | |||
| Dolby Surround | Yes | |||
| DTS:X | Yes | |||
| DTS-HD Master Audio | Yes | |||
| Auro 3D | Yes | |||
| Audio Features | File Format | MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz | ||
| Pure Direct | Yes | |||
| Compressed Music Enhancer | Yes | |||
| High-resolution Music Enhancer | Yes | |||
| YPAO Multipoint Measurement | Yes with R.S.C. (Reflected Sound Control), 3D, 64-bit High Precision EQ Calculation, Low Frequency mode and Angle Measurement | |||
| YPAO Volume | Yes | |||
| Adaptive DRC (Dynamic Range Control) | Yes | |||
| Initial Volume and Maximum Volume Setting | Yes | |||
| A.R.T. Wedge | Yes | |||
| Bi-amp Capability | Yes | |||
| Audio Delay | Yes (0-500 ms) | |||
| DA Converter | 384 kHz / 32-bit ESS Hyperstream DAC ES9026PRO x1 ES9007S x1 | |||
| Video Features | HDMI eARC | Yes | ||
| HDMI Audio Return Channel | Yes | |||
| HDMI Pass-through | 4K120AB, 8K60AB, 4K60 and 40GBPS | |||
| HDMI Upscaling | Yes, up to 8K | |||
| HDMI Up-conversion | Yes (Analog to HDMI) | |||
| Dolby Vision | Yes | |||
| HDR 10+ | Yes | |||
| VRR & ALLM | Yes | |||
| Video Adjustment | Yes | |||
| Connectivity | MusicCast Surround | Yes | ||
| Wi-Fi | Yes (2.4 / 5 GHz) | |||
| AirPlay 2 | Yes | |||
| Bluetooth | Yes (SBC / AAC) | |||
| Phono Input | Yes | |||
| XLR Terminal | Yes | |||
| Component Video Input/Output | 1 / 0 | |||
| Extensive Connections | HDMI Input/Output | 7 / 3 (HDMI 2.1 / HDCP 2.3) | ||
| HDMI CEC | Yes | |||
| USB Input | Yes | |||
| Network Port | Yes | |||
| Front AV Input | USB | |||
| Digital Audio Input / Output: Optical | 3 / 0 | |||
| Digital Audio Input / Output: Coaxial | 2 / 0 | |||
| Analog Audio Input / Output | 6 / 0 | |||
| Composite Video Input / Output | 2 / 0 | |||
| Preout | 11.2-ch | |||
| Headphone Output | 1 | |||
| Tuner Section | FM / AM Tuner | Yes | ||
| User Interface | On-Screen Display | Graphical User Interface | ||
| SCENE | SCENE PLUS (8 sets) | |||
| App Control | Yes (iPhone / iPad / Android phone / tablet) | |||
| Web Browser Control | Yes | |||
| Remote Control Unit | Yes | |||
| Zone Control | Zone 2 Audio Output | Preout / HDMI | ||
| Zone 3 Audio Output | Preout | |||
| Zone 4 Audio Output | HDMI | |||
| Powered Zone | Zone 2 / 3 | |||
| Zone Video Output | HDMI | |||
| Zone B Output | HDMI | |||
| Zone GUI | Yes | |||
| RS-232C Interface | N/A | |||
| +12V Trigger Output | 2 | |||
| Remote (IR) Input/Output | 1 / 1 | |||
| Party Mode | Yes | |||
| General | Standby Power Consumption (IR only) | <0.4 W | ||
| Auto Power Standby | Yes | |||
| ECO Mode | Yes | |||
| Dimensions (W x H x D) | 17-1/8" x 7-1/2" x 17-3/8" (with antenna up:17-1/8" x 10-5/8" x 17-3/8") | |||
| Weight | 41.2 lbs. | |||
