Description
Product Details
Improves Picture and Sound Quality
The MFP-300’s Power Cleaning and Premium Filtration eliminate common symptoms of contaminated power (including loss of detail, pops, hisses, hums and visual artifacts) and allows your A/V equipment to perform up to its full capability.
Surge Protection
Panamax’s exclusive Protect or Disconnect™ circuitry. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.
Features
- Premium Filtration Improves Picture and Sound.
- Provides clean power by filtering out noise common to household power.
- HD Ready
- Designed to work with your High Definition system.
- 2 Outlets
- Both outlets feature always-on filtration.
- Surge Protection
- Exclusive Protect or Disconnect™ circuitry. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.
- Cable/Sat. Protection
- Protects equipment from electrical surges that travel over Cable, Satellite, and Antenna lines.
Specifications
Voltage Protection Rating (UL 1449 3rd Edition, 3,000A): 330V
UL991 Electronic Safety Circuit: Yes
Single Pulse Energy Dissipation: 1675 Joules
Response Time: < 1ns
Peak Impulse Current: 48,000 Amps
Universal Coaxial Protection
Shielded: Yes
Insertion Loss: < 0.5 dB
Frequency Range: 0MHz – 2.2 GHz
Connections: Female “F”, Gold Plated
Clamping Level: 75V
Bidirectional: Yes
