Product Details
Exclusive Protect or Disconnect™ Circuitry
Safeguards equipment against all surges. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.
Noise Filtration Circuit
EMI/RFI Filtration Circuitry for Clean, Unimpeded Power.
LAN/Telco Protection
Protects equipment from electrical surges that travel over low voltage LAN/Tel lines.
$100,000 Limited Connected Equipment Protection Warranty
Panamax will protect your equipment or we will repair or replace up to $100,000!
Lifetime Product Warranty
The surge protector shall be free of any defects in design, materials, or workmanship, and Panamax will repair or replace any defective unit.
Features
- EMI/RFI Filtration Circuitry for Clean, Unimpeded Power.
- Protect-or-Disconnect™ Circuitry
- In/Out Telco/LAN Connectors.
- Removable, paintable cover ensures seamless fit with any décor.
- Two Diagnostic Lights (LED) Power On/Protection OK and Line Fault.
- Thin Profile – Only 1.5 inches deep.
- Convenient display feature; turn cover around to hide diagnostic lights.
Specifications
Voltage Protection Rating (UL 1449 3rd Edition, 3,000A): L-N 400V, L-G 500V, N-G 500V
Thermal Fusing: Yes
Single Pulse Energy Dissipation: 1350 Joules
Response Time: <1 ns
Peak Impulse Current: 60,000 A
Nominal Discharge Current: 3,000 A
LAN Specifications
Wires Protected: Pins 1, 2, 3, & 6
Suppression Modes: Differential & Common Ground
Connectors: RJ-45 Shared with Telco
Compatibility: 10/100 BASE-T
Clamping Level: 7V
Telco Specifications
Wires Protected: 2 wire, 1 pair (4,5)
Suppression Modes: Metallic & Longitudinal
Fuseless/Auto-Resetting: Yes
Connectors: RJ-45 Shared with LAN
Clamping Level: 260V
Capacitance: 30 pf (approx.)
