Description
Product Details
SMP (Series Multi-Stage Protection Plus)
Furman SMP surge suppression virtually eliminates service calls. Traditional surge suppression circuits sacrifice themselves when exposed to multiple transient voltage spikes, requiring the dismantling of your system and repair of your surge suppressor. Not so with SMP. With Furman SMP, damaging transient voltages are safely absorbed, clamped, and dissipated – no sacrificed parts, no service calls, no downtime.
Unique to Furman SMP is its unparalleled clamping voltage, even when tested beyond the grueling specifications of USA/CIDA’s A-1-1 test. While other designs offer clamping voltages that are well above 300VAC peak (far beyond long accepted professional standards), Furman SMP clamps at 188VAC peak, 133 VAC RMS even when tested with multiple 6000VAC – 3000 Amp surges! This unprecedented level of protection is only available with Furman SMP technology.
LiFT (Linear Filtering Technology)
Unfortunately, traditional AC filter/conditioners have been designed for unrealistic laboratory conditions. Prior technologies could actually harm audio and video performance more than they help, due to the resonant peaking of their antiquated, non-linear designs. Under certain conditions, these designs can actually add more than 10 dB of noise to the incoming AC line. Worse still, lost digital data, the need to reboot digital presets, or destroyed digital converters are frequently caused by excessive voltage spikes and AC noise contaminating the equipment ground. Furman SMP with LiFT takes another approach, ensuring optimal performance through linear filtering and no leakage to ground.
E.V.S. (Extreme Voltage Shutdown)
Furman trusted overvoltage circuitry protects against all-too-frequent accidental connections to extreme voltage by shutting off the incoming power until the overvoltage condition is corrected.
Compact Chassis Design
At only 1.75”H x 5”W x 8.5”D, and weighing in at only 3 lbs., the compact, low-profile design of the AC-210A E makes it ideal for mounting to the back of a flat-screen television, or anywhere that discretely located, remote power protection and purification are needed.
Specifications
Family: AC Series
Line Voltage: 120 Volts
Number of Outlets: 2
Outlet Description: Both outlets filtered and surge protected
Control: On/Off control to all outlets through power switch
Compliance: cTUVus Certified
Dimensions: 5" W x 8.5" D x 1.75" H
Weight: 3 lbs
AC Protection Technology
- Extreme Voltage Shutdown
- Multi-Stage Protection
- Non-sacrificial protection with zero ground contamination
Undervoltage Shutoff: N/A
Over-Voltage Shutoff: 137 VAC
Maximum Current Rating: 10 Amps
Initial Clamping Level: 188V peak clamping @ 6000V/3000A input
Filtration Technology: LiFT
Filtration Rating: 40 dB from 100 kHz – 100 MHz > 50dB from 500 kHz – 1GHz
Signal Line Protection: No
UPC: 654061028246
Proposition 65 Warning: Warning: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
