Description
TEMPO724Q NETWORK PROGRAM 24/7 TIMER
Altronix Tempo724Q Network Timer is designed to support a wide range of applications such as Home and Building Automation, Security, Access Control, Lighting Control, and more. Tempo724Q is equipped with two independently controlled form “C” relay contacts that provides many latching and/or momentary operations during a program schedule of your
choice. LINQ™ Network management technology allows for remote control, programming, and reporting of diagnostics via Email/Dashboard. Events may be set for single or multiple
operations on a daily and/or weekly schedule.
Input
Voltage: 12VDC/24VDC operation or PoE (12.95W, Class 3)
Aux: 12V 100mA, 24 V 80mA
Relays
Contact Rating: Form “C” 5A 24VDC/120VAC.
Standby Current: 10mA (relay off) or 50mA (relay on).
Timer Features
Flash memory protects against loss of programming due to power failure.
Accurate crystal controlled clock.
Momentary and/or Latching Events.
60 individually programmed daily/weekly events.
Block programming capacity can accommodate a total of 420 events per week.
30 programmable Holiday dates.
Automatic compensation for leap year.
LINQ Technology
Remote programming.
Programable users.
USB Network programming.
Email and Windows Dashboard Alert notifications report real-time diagnostics.
Event log tracks history.
Timer Alerts
System Start up
“First man in” option
- FM1 Active / Inactive
- FM2 Active / Inactive.
Standard or Daylight Savings Time settings
- Enabled / Disabled.
Relays
- Relay Channel 1: On/Off
- Relay Channel 2: On/Off.
Trigger Inputs (Programmed, relay does not change state)
- Trigger 1 Active / Inactive
- Trigger 2 Active / Inactive
LED Indicators
PoE input.
AUX power input.
Battery LED.
Heartbeat (flashing).
Battery Charging
Type: Sealed lead acid or gel type.
Current: 0.25A.
Failover Upon AC loss, instantaneous.
Temperature
Operating -20ºC to 49ºC ( -4ºF to 120ºF).
Storage: -25ºC to 70ºC ( -13ºF to 158ºF).
Relative Humidity: 85% +/- 5%.
