Altronix NETWAYSP4TCW53 4PT FB MD CV/360W/BT

Altronix NETWAYSP4TCW53 4PT FB MD CV/360W/BT Altronix NetWaySP4TCW53 supports up to 90W per port (360W total power) for deploying the latest high-powered IP devices in remote locations. It is equipped with two (2) 1Gb SFP ports to transmit data at long distances and four (4) 802.3bt (90W) Ethernet ports. NetWaySP4TCW53 accommodates single/multi-mode fiber cable to deliver power from NetWay Spectrum headend media converters/injectors. NetWaySP4TCW53 has an integrated rapid battery charger for extended battery run times. Embedded LINQ Technology allows to monitor, control, and report power and diagnostics from anywhere. Input Voltage: 115VAC, 60Hz, 3.5A or 230VAC, 50/60Hz, 2A Input Fuse: 5A/250V Power Output Maximum Power: Four (4) PoE ports rated at 90W each, 360W total power IEEE 802.3af (15W), IEEE 802.3at (30W), IEE 802.3bt (90W) compliant Integral surge protection SFP Ports: Two (2) Gigabit SFP ports Ethernet Ports Four (4) 10/100/1000 Mbps ports Connectivity: RJ45, auto-crossover Wire type: 4-pair CAT5e or higher structured cable Speed: 10/100/1000 Mbps, half/full duplex, auto negotiation Battery Charging Type: 48VDC charging circuit charges sealed lead acid or gel type batteries Selectable 2A or 4A charging circuit Able to recharge 32AH or larger batteries in under 8 hours Low battery and battery presence supervision AC Fail supervision Failover: Upon AC loss, instantaneous (Batteries are sold separately) (Vent2 Ventilation Kit is included) Indicators (LED) Individual PoE On LEDs for each port Individual IP Link status, 10/100/1000 Base-T/active LEDs for each port ALOS LED indicates fiber connection for SFP port Heartbeat LED indicates proper operation of the unit VLAN: Multiple management VLAN assignment 802.1Q Tagged VLAN Up to 10 VLAN groups. ID Range 2-4095 LINQ Technology: Remote network management allows for camera/device reset and diagnostic monitoring Provides local and/or remote access to critical information via LAN/WAN Email and Windows Dashboard Alert notifications report real-time events Event log tracks history Temperature Operating (360W): – 30ºC to 65ºC (– 22ºF to 149ºF) Operating (240W): – 30ºC to 70ºC (– 22ºF to 158ºF) Storage: – 30ºC to 85ºC (– 22ºF to 185ºF) Relative Humidity: 85% +/– 5% BTU/Hr. (approx.): 183 BTU/Hr. Operating Altitude: – 304.8 to 2,000m.
